Edge Cutting Machine Bridge Type (HSQ1200B)
HSQ-1200 Bridge Type Edge Cutting Machine uses wide-span bridge type structure, and is equipped with 90°rotary cutting table. By moving the girder horizontal stone slicing can be realized. With this machine, slabs of great lengths and depths can be processed with flexibility in rotation, precise in positioning, great in strength, and stable in operation. Imported frequency converter is used for the mainbody to achieve stepless adjustment of cutting speed. It is applicable of cutting valuable of cutting valuable tombstones.
| Blade diameter | Φ600-Φ1200 mm |
| Blade vertical stroke | 620 mm |
| General power | 22 kw |
| Water consumption | 4 m3/h |
| Size of cutting table | 3000×2000 mm |
| Cutting table rotation range | 0°，90° n° |
| Dimensions(L×W×H) | 6400×4700×3800 mm |
| Beam slicing method | Manual measurement/optional automatic film mode (PLC computer control) |
| Weight | 6 T |
