PVC Air Blowing Machine
HIGH QUALITY MACHINE WITH ALL BRANDED PARTS AND FUNCTIONS . WE SUPPLY PVC AIR BLOWING MACHINE, AND MOULDS FOR FOOTWEAR.
PVC air blowing machine manufacture is especially suitable for singing TPR / PVC soles for PVC / TPR soles. After modifying a litter bit on the machine can produce soft toy. A set of independent circuit systems to provide strong injection pressure and flow that is suitable for all types of mold using foaming or non-foaming PVC or TPR raw materials. To produce direct injections without shoes soles, upper sandal and sandals or straight plastic shoes.
| Material | PVC. TPR |
| Work Station | 24 |
| Mould Closed Pressure | 60000 KG |
| Mould Space (Max) | 260 MM |
| Diameter Of Screw | 75 MM |
| Max. Injection Capacity | 600/800 G |
| Injection Pressure | 140 KG/CM |
| Rotating Speed of Screw | 0-165 R.P.M |
| Temprature Control | 4 Section |
| Hearer of Barrel | 6.9 KW |
| Motor | 25/30 HP |
| Total Power | 29 KW |
| Dimention | 7000X3650X3000 MM |
| Total Weight | 7500 kg |
