DL-310 with CPU Control
LOW PRESSURE LOW SPEED POLYURETHANE(PU) POURING MACHINE WITH 60 STATION CONVEYOR, OVEN, CHILLER,TRIMMING MACHINE-1 & OTHER ACCESSORIES WITH AC DRIVE AND HIGH FREQUENCY GEAR BOX MODEL NO. DL- 310 WITH COLOUR DOSING SYSTEM
| SL.NO. | MODEL | UNIT | MODEL DL – 310 WITH CPU Control |
| 1 | STATIONS | NOS | 60 |
| 2 | CLAMPING ORCE | TONS | NIL |
| 3 | TOTAL POWER | KW | 63 |
| 4 | MIXING HEAD | R.P.M | 8000 |
| 5 | HEAD | TYPE | MOVEABLE |
| 6 | MOULD OPENING/CLOSING | ------- | MANUAL |
| 7 | HEATING OIL CAPACITY | LITERS | 420 |
| 8 | PRODUCTION | 12 HRS | 25000/PRS |
| 9 | DIEMENTION OF MACHINE | L X W X H(MTRS) | 19 X 2 X 1.45 |
| 10 | WEIGHT OF THE MACHINE | TONS | 7.5 |
| 11 | AC DRIVE | NOS. | 4 |
| 12 | CPU CONTROL | - | PLC TOUCH SCREEN |
| 13 | AUTO WASHING | - | Yes |
| 14 | AUTO START | - | Yes |
| 15 | INDIVIDUAL PRODUCTION COUNTER | - | Yes |
| 16 | MATERIAL WASTAGE COUNTER | - | Yes |
| 17 | RATIO ADJUSTABLE FROM TOUCH SCREEN | - | Yes |
| 18 | MULTI COLOUR PRODUCTION | - | 5 COLOURS |
| 19 | DOUBLE DENSITY PRODUCTION | - | Yes |
| N.W. | 1300kg | ||
| Dimension(LWH) | 1750x1050x1950mm | 6 T |
Product Display
